ATUS-A10VG Series Axial Piston Variable Displacement Pump

ATUS-A10VG Features:


- A10VG series has 18, 28, 45, 63 cc. displacement specifications available;
- Nominal pressure 300 bar;
- Peak pressure 350 bar;
- Swash plate design axial piston variable pump for hydrostatic transmission in closed circuit;
- Flow is proportional to drive speed and displacement and is infinitely variable;
- Output flow increases as the swash plate oscillation angle increases from 0 to its maximum value;
- Flow direction changes smoothly when the swash plate passes the neutral position;
- A wide range of highly adjustable control devices for different control and regulation functions;
- The pump is equipped with two pressure relief valves on the high pressure oil port side to prevent overload of the hydrostatic transmission (pump and motor);
- The high-pressure relief valve can also be used as an oil replenishment valve;
- The built-in replenishment pump acts as a feed pump and an oil control pump;
- The maximum replenishment pressure is limited by the built-in replenishment relief valve.
